| الاسم التجاري: | SKYLINE |
| مو: | 1 |
| السعر: | Negotiate |
| شروط الدفع: | تي/تي |
| القدرة على التوريد: | 1 مجموعة / شهر |
| Parameter | 500W (5V class) | 50W (HB/V class) |
|---|---|---|
| Test Flame | 500W (V-0,V-1,V-2 classification) | 50W (V-0,V-1,V-2 classification) |
| Burner Tube | Φ 9.5mm±0.3mm | Φ 9.5mm±0.3mm |
| Burning Angle | 0°,20°,45° | 0°,20°,45° |
| Thermocouple | Type K (Ni/Cr - Ni/Al) | Type K (Ni/Cr - Ni/Al) |
| Thermocouple Size | 0.5 mm | 0.5 mm |
| Standard Copper Block | 9mm±0.01mm, 10g±0.05g | 5.5mm±0.01mm, 76g±0.01g |
| Time for Temperature Increase | 100°C→700°C: 54s±2s | 100°C→700°C: 44s±2s |
| Gas Flow | 965±32ml/min | 105±10ml/min |
| Gas Supply | Methane, ≥98% purity | Methane, ≥98% purity |
| Water-column | 125m±5mm | <10mm |
| Test Time | 54±2s | 44±2s |
| Flame Height Indicator | 40±1mm | 20±1mm |
| Volume Of Chamber | >0.5m³, black interior | >0.5m³, black interior |
| Conform to standard | UL94, IEC60695-11-3, IEC60695-11-20 | UL94, IEC60695-11-4, IEC60695-11-10 |
